Sinker EDM

Power Generator

Tool Type EDM

Custom Made EDM

EDM Tooling/Access.


GROMAX>EDM>Sinker EDM>CNC Sinker EDM>Products


| conventional sinker edm | znc sinker edm | cnc sinker edm |

CNC Sinker EDM

Ram Type Column Type
CNCP36+E75H (39"x22"x16"" tank)
CNCP50+E100H (50"x28"x18" tank)		 CNCP60+E100H (59"x40"x25.5" tank)
CNCP70+E150H (71"x43"x25" tank)
CNCP80+E200H (83"x46"x28" tank)
CNCP110+E300H (110"x59"x28" tank)
CNCP130+E300H (134"x61"x28" tank)


TOP

CNCP36+E75H: CNC Sinker EDM (ram type)


$97,000.00



Specifications:
TABLE
Dimensions 25.6"x13.8"
Longitudinal & Traversal Travel 16.0"x12.5"
Max. Work Piece (LxWxH) 33"x20"x16"
Max. Work Piece WT. 2200 Lbs.
WORK TANK
Inside Dimensions 39"x22"x16"
WORK HEAD
Backslide Travel 11.5"
Quill Travel 7.25"
Max. Distance Table Top to Electrode Plate Surface 23.7"
Max. Electrode Wt. 330 Lbs.
PACKING DIMENSIONS (LxWxH) 55"x53"x87"
Net Weight 2860 Lbs
DIELECTRIC RESERVOIR
Outside Dimensions (LxWxH) 32"x28"x28"
Capacity 63 Gal.
Cartridge Filter 2
Net Weight 180 Lbs.
Packing Dimensions (LxWxH) 40"x40"x35"
GENERATOR (Heidenhain TNC416 Controller) E75H
Max. Machining 75A
Current Power Input 9 KVA
Practical Material Removal Rate w/o Wear 0.5 In3/H
Max. Material Removal Rate 2.1 In3/H
Max. Electrode Wear 0.5%
Best Surface Finishing U/Rmax 0.3
Net Weight 396 Lbs.
Packing Dimensions 35"x29"x79"


TOP
CNCP46+E100H: CNC Sinker EDM (ram type)



Click for larger view.

$111,400.00



Specifications:
TABLE
Dimensions 29.5"x17.6"
Longitudinal & Traversal Travel 18"x14.5"
WORK TANK
Inside Dimensions 50"x28"x18"
WORK HEAD
Backslide Travel 13"
Quill Travel 14"
Max. Distance Table Top to Electrode Plate Surface 28.25"
PACKING DIMENSIONS
Machine Base (LxWxH) 34"x54"x85"
DIELECTRIC RESERVOIR
Outside Dimensions (LxWxH) 68"x68"x87"
GENERATOR (Heidenhain TNC416 Controller) E100H
Max. Machining 100A
Current Power Input 10 KVA
Practical Material Removal Rate w/o Wear 0.5 In3/H
Max. Material Removal Rate 2.9 In3/H
Max. Electrode Wear 0.5%
Best Surface Finishing U/Rmax 0.3
Net Weight 550 Lbs.
Packing Dimensions 47"x32"x79"


TOP

CNCP60+E100H: CNC SInker EDM (column type)


Click for larger view.

$125,800.00

Specifications:
TABLE
Dimensions 39.4"x23.6"
Longitudinal & Traversal Travel 27.6"x19.7"
Max. Work Piece (LxWxH) 57"x34"x23"
Max. Work Piece WT. 8800 Lbs.
WORK TANK
Inside Dimensions 59"x40.2"x25.6"
WORK HEAD
Quill Travel 15.75"(25.6" optional)
Max. Distance Table Top to Electrode Plate Surface 32.5"(38.5"/48.5" optional)
Max. Electrode Wt. 660 Lbs.
PACKING DIMENSIONS (LxWxH)
Machine Base 81"x70"x110"
Net Weight 12,100 Lbs
DIELECTRIC RESERVOIR
Outside Dimensions (LxWxH) Tank 1 56.5"x54"x34"
Tank 2 56.5"x54"x34"
Capacity 413 Gal.
Cartridge Filter 4
Net Weight 660 Lbs.
Packing Dimensions (LxWxH) 64.5"x62"x42"
GENERATOR (Heidenhain TNC416 Controller) E100H
Max. Machining 100A
Current Power Input 10 KVA
Practical Material Removal Rate w/o Wear 0.5 In3/H
Max. Material Removal Rate 2.9 In3/H
Max. Electrode Wear 0.5%
Best Surface Finishing U/Rmax 0.3
Net Weight 550 Lbs.
Packing Dimensions 47"x32"x79"


TOP
CNCP70+E150H: CNC Sinker EDM (column type)


$132,800.00



Specifications:
TABLE
Dimensions 47.2"x31.5"
Longitudinal & Traversal Travel 39.4"x23.6"
Max. Work Piece (LxWxH) 68"x41"x25"
Max. Work Piece WT. 11000 Lbs.
WORK TANK
Inside Dimensions 71"x43"x25"
WORK HEAD
Quill Travel 15.8"
(23.6" optional)
Max. Distance Table Top to Electrode Plate Surface 28.8"(34.6"/44.5" optional)
Max. Electrode Wt. 660 Lbs.
PACKING DIMENSIONS (LxWxH)
Machine Base 103"x92"x79"
Head & Shoulder 90"x40"x76"
Net Weight 14,500 Lbs
DIELECTRIC RESERVOIR
Outside Dimensions (LxWxH) Tank 1 98"x74"x52"
Tank 2 101"x76"x44"
Capacity 490 Gal.
Cartridge Filter 4
Net Weight 990+770 Lbs.
Packing Dimensions (LxWxH) 100"x76"x43" (x2 pcs)
GENERATOR (Heidenhain TNC416 Controller) E150H
Max. Machining 150A
Current Power Input 15 KVA
Practical Material Removal Rate w/o Wear 0.5 In3/H
Max. Material Removal Rate 5.12 In3/H
Max. Electrode Wear 0.5%
Best Surface Finishing U/Rmax 0.3~0.5
Net Weight 1350 Lbs.
Packing Dimensions 68"x42"x88"


TOP
CNCP80+E200H: CNC Sinekr EDM (column type)


$158,200.00



Specifications:
TABLE
Dimensions 55.1"x35.5"
Longitudinal & Traversal Travel 43.3"x27.6"
Max. Work Piece (LxWxH) 78"x44"x27"
Max. Work Piece WT. 13000 Lbs.
WORK TANK
Inside Dimensions 83"x46"x28"
WORK HEAD
Quill Travel 17.7"
(23.6" optional)
Max. Distance Table Top to Electrode Plate Surface 37.8"(43.7"/49.6" optional)
Max. Electrode Wt. 1100 Lbs.
PACKING DIMENSIONS (LxWxH)
Machine Base 125"x98"x95"
Head & Shoulder 108"x46"x96"
Net Weight 16500 Lbs
DIELECTRIC RESERVOIR
Outside Dimensions (LxWxH) Tank 1 115"x50"x74"
Tank 2 108"x46"x96"
Capacity 529 Gal.
Cartridge Filter 4
Net Weight 1100+1100 Lbs.
Packing Dimensions (LxWxH) 123"x57"x82" (x2 pcs)
GENERATOR (Heidenhain TNC416 Controller) E200H
Max. Machining 200A
Current Power Input 20 KVA
Practical Material Removal Rate w/o Wear 0.5 In3/H
Max. Material Removal Rate 5.12 In3/H
Max. Electrode Wear 0.5%
Best Surface Finishing U/Rmax 0.3~0.5
Net Weight 1350 Lbs.
Packing Dimensions 68"x40"x90"


TOP
CNCP110+E300H: CNC Sinker EDM (column type)


$215,700.00



Specifications:
TABLE
Dimensions 78.7"x39.4"
Longitudinal & Traversal Travel 82.7"x39.4"
Max. Work Piece (LxWxH) 108"x59"x27"
Max. Work Piece WT. 22000 Lbs.
WORK TANK
Inside Dimensions 110"x59"x28"
WORK HEAD
Quill Travel 23.6"
Max. Distance Table Top to Electrode Plate Surface 53.1"
Max. Electrode Wt. 1100 Lbs.
PACKING DIMENSIONS (LxWxH)
Machine Base 150"x90"x80"
Head & Shoulder 120"x36"x91"
Work Tank 144"x72"x33"
Net Weight 23980 Lbs
DIELECTRIC RESERVOIR
Outside Dimensions (LxWxH) Tank 1 121"x61"x81"
Tank 2 121"x61"x81"
Capacity 792 Gal.
Cartridge Filter 4+4
Net Weight 1760+1760 Lbs.
Packing Dimensions (LxWxH) 129"x69"x89" (x2 pcs)
GENERATOR (Heidenhain TNC416 Controller) E300H
Max. Machining 300A
Current Power Input 30 KVA
Practical Material Removal Rate w/o Wear 0.5 In3/H
Max. Material Removal Rate 7.68 In3/H
Max. Electrode Wear 0.7%
Best Surface Finishing U/Rmax 0.3~0.5
Net Weight 1450 Lbs.
Packing Dimensions 68"x40"x90"


TOP
CNCP130+E300H: CNC Sinker EDM (column type)



Click for larger view.

$233,000.00



Specifications:
TABLE
Dimensions 98.4"x39.4"
Longitudinal & Traversal Travel 98.4"x39.4"
Max. Work Piece (LxWxH) 130"x60"x27"
Max. Work Piece WT. 25000 Lbs.
WORK TANK
Inside Dimensions 134"x61"x28"
WORK HEAD
Quill Travel 23.6"
Max. Distance Table Top to Electrode Plate Surface 59.1"
Max. Electrode Wt. 1100 Lbs.
PACKING DIMENSIONS (LxWxH)
Machine Base 150"x90"x80"
Head & Shoulder 120"x36"x91"
Work Tank 144"x72"x33"
Net Weight 23980 Lbs
DIELECTRIC RESERVOIR
Outside Dimensions (LxWxH) Tank 1 170"x89"x107"
Tank 2 134"x41"x100"
Capacity 910 Gal.
Cartridge Filter 4+4
Net Weight 2200+1980 Lbs.
Packing Dimensions (LxWxH) 142"x78"x85" (x2 pcs)
GENERATOR (Heidenhain TNC416 Controller) E300H
Max. Machining 300A
Current Power Input 30 KVA
Practical Material Removal Rate w/o Wear 0.5 In3/H
Max. Material Removal Rate 7.68 In3/H
Max. Electrode Wear 0.7%
Best Surface Finishing U/Rmax 0.3~0.5
Net Weight 1450 Lbs.
Packing Dimensions 68"x40"x90"
